DT15
Specifications
MODEL DT15
ENGINE TYPE 2-Stroke 2 Cylinders
FUEL DELIVERY SYSTEM Carburetor
TRANSOM HEIGHT mm (in.) S: 381 (15) | L: 508 (20)
STARTING SYSTEM Manual
WEIGHT kg (Ibs.) S: 33 (73) | L: 35 (77)
NO. OF CYLINDERS 2 (Inline)
PISTON DISPLACEMENT cm³ (cu. in.) 284 (17.3)
BORE × STROKE m/m (in.) 59 × 52 (2.32 × 2.05)
MAXIMUM OUTPUT 15 (11)/5200
PS (kW)/rpm
FULL THROTTLE 4800–5600
OPERATING RANGE rpm
STEERING Tiller
OIL PAN CAPACITY – (Premix fuel/oil)
IGNITION SYSTEM Suzuki P.E.I.
ALTERNATOR 12V 80W (Optional)
GEAR RATIO 1.92 : 1
GEAR SHIFT F-N-R
TRIM METHOD Manual Trim & Tilt
FUEL / OIL MIXING RATIO 50 : 1
